EX46100

ISO
• Manufactured in an ISO9001 facility

EMI
FCC Part 15B, Class A
EN61000-6-4
EN55022 Class A

EMS
EN61000-6-2
• EN61000-4-2 (ESD Standards)
• EN61000-4-3 (Radiated FRI Standards)
• EN61000-4-4 (Burst Standards)
• EN61000-4-5 (Surge Standards)
• EN61000-4-6 (Induced RFI Standards)
• EN61000-4-8 (Magnetic Field Standards)

Environmental Test Compliance
IEC60068-2-6 Fc (Vibration)
IEC60068-2-27 Ea (Shock)
FED STD 101C Method 5007.1 (Free fall w/ package)

Industrial Compliance
NEMA TS2

Operating Temperature
• -40°C to 75°C (-40°F to 167°F)
Tested @ -40°C to 85°C (-40°F to 185°F)

Web-smart Function Operating Temperature
• -20°C to 75°C (-4°F to 167°F)

Storage Temperature
• -40°C to 85°C (-40°F to 185°F)

Ambient Relative Humidity
• 5% to 95% (non-condensing)

Input
• Redundant power inputs:
Terminal Block: 47 - 57VDC
DC Jack: 47 - 57VDC

Power Consumption
• Device: Max. 10W (without PoE)
• PoE power budget (depends on power input): 120W Max.

PoE Power Output
• Port 1 to 4
• IEEE802.3af+: up to 30W/port, 47 - 57VDC, 600mA Max.

Protection
• Reverse polarity protection
