Operating Temperature
• -40°C to 75°C (-40°F to 167°F)
Tested @ -40°C to 85°C (-40°F to 185°F)

Storage Temperature
• -40°C to 85°C (-40°F to 185°F)

Ambient Relative Humidity
• 5% to 95% (non-condensing)

IEC 60068-2-6 Fc (Vibration Resistance)
IEC 60068-2-27 Ea (Shock)
FED STD 101C Method 5007.1 (Free fall w/ package)

Industrial Compliance
NEMA TS2

ISO
• Manufactured in an ISO 9001 facility

EMI
FCC Part 15B Class A
VCCI Class A
EN55022
EN61000-3-2
EN61000-3-3
EN61000-6-4

Safety
UL 508

EMS
EN 61000-6-2
• EN 61000-4-2 (ESD Standards)
• EN 61000-4-3 (Radiated RFI Standards)
• EN 61000-4-4 (Burst Standards)
• EN 61000-4-5 (Surge Standards)
• EN 61000-4-6 (Induced RFI Standards)
• EN 61000-4-8 (Magnetic Field Standards)

Input Voltage
• 12 to 48VDC (Terminal Block)
• 12VDC (DC Jack)

Power Consumption
• 7.68W Max, 0.16A @ 48VDC

Protection
• Overload current protection
• Reverse polarity protection
