IEC60068-2-6 Fc Vibration Resistance
IEC60068-2-27 Ea Shock
FED STD 101C Method 5007.1 Free fall w/ package

Industrial Compliance
IEEE61850-3 / IEEE1613
EN50121-4
NEMA TS2

ISO
• Manufactured in an ISO9001 facility

EMI
FCC Part 15B, Class A
EN61000-6-4
EN55022
EN61000-3-2
EN61000-3-3

EMS
EEN61000-6-2
• EN61000-4-2 (ESD Standards)
• EN61000-4-3 (Radiated RFI Standards)
• EN61000-4-4 (Burst Standards)
• EN61000-4-5 (Surge Standards)
• EN61000-4-6 (Induced RFI Standards)
• EN61000-4-8 (Magnetic Field Standards)
• IEC61000-4-10 (Oscillatory wave magnetic field test)
• IEC61000-4-16 (Power frequency immunity test)
• IEC61000-4-18 (Oscillatory wave immunity test)

Operating Temperature
• -40°C to 75°C -40°F to 167°F
Tested @ -40°C to 80°C -40°F to 176°F

Storage Temperature
• -45°C to 85°C -49°F to 185°F

Ambient Relative Humidity
• 5% to 95% non-condensing

Input Voltage
• 12 - 48VDC Terminal Block
• 12VDC DC Jack

Power Consumption
• 15W Max. 1.25A @ 12VDC, 0.625A @ 24VDC

Protection
• Reverse polarity protection
