Operating Temperature
• -40°C to 75°C (-40°F to 167°F)
Tested @ -40°C to 85°C (-40°F to 185°F)

Storage Temperature
• -45°C to 85°C (-49°F to 185°F)

Ambient Relative Humidity
• 5% to 95% (non-condensing)

IEC61373 (Vibration) for EN50155
IEC61373 (Shock) for EN50155
IEC600680-2-32 Ed (Free fall)

Industrial Compliance
EN50155
EN50121-3-2
EN50121-4

ISO
• Manufactured in an ISO9001 facility

EMI
FCC Part 15B, Class A
EN61000-6-4
EN55022
EN55011 (for EN50155)

EMS
EN61000-6-2
• EN61000-4-2 (ESD Standards)
• EN61000-4-3 (RFI Standards)
• EN61000-4-4 (Burst Standards)
• EN61000-4-5 (Surge Standards)
• EN61000-4-6(Induced RFI Standards)
• EN61000-4-8 (Magnetic Field Standards)
• EN61000-4-9 (Pulsed magnetic field)

Input
• Redundant power inputs:
M23: 12 - 48VDC (non-PoE model)
M23: 55 (52 to 57) VDC

Power Consumption
• Device: Max. 11W (without PoE)
• PoE power budget (depends on power input): 240W Max

PoE Technology
• Alternative A
Pins 1/2(+), 3/6(-)

PoE Power Output
• Port 1 to 8: IEEE802.3at, up to 30W/port, 47 - 57VDC

Protection
• Reverse polarity protection
