IEC60068-2-6 Fc (Vibration)

Input
• Redundant power input:
Terminal Block: 47 - 57VDC
DC Jack: 47 - 57VDC

Power Consumption
• Device: Max. 15W (without PoE)
• PoE power budget (depends on power input): 181.6W Max.

PoE Power Output
• Port 1 to 8 support PoE
• IEEE802.3af: up to 15.4W/port, 47 - 55VDC.
• IEEE802.3at: up to 30W/port, 52 - 57VDC

Protection
• Reverse polarity protection

ISO
• Manufactured in an ISO9001 facility

Safety
UL508

EMI
FCC Part 15B, Class A
EN61000-6-4
EN55022
EN61000-3-2
EN61000-3-3

EMS
EN61000-6-2
• EN61000-4-2 (ESD Standards)
• EN61000-4-3 (Radiated RFI Standards)
• EN61000-4-4 (Burst Standards)
• EN61000-4-5 (Surge Standards)
• EN61000-4-6 (Induced RFI Standards)
• EN61000-4-8 (Magnetic Field Standards)

Operating Temperature
• -40°C to 75°C (-40°F to 167°F)
Tested @ -40°C to 85°C (-40°F to 185°F)

Storage Temperature
• -45°C to 85°C (-49°F to 185°F)

Ambient Relative Humidity
• 5% to 95% (non-condensing)
